上海拓起起重设备有限公司
产品特性：
产品参数：
| 荷载量(kg) | 型号 | 高度(m) | 升降速度(m/min) | 输出功率(kw) | 运行速度(m/min) | 电机功率(kw) |
| 2000 | MLER02-06S | 6 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 |
| MLER02-09S | 9 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER02-12S | 12 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER02-15S | 15 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER02-18S | 18 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| 3200 | MLER3.2-06S | 6 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 |
| MLER3.2-09S | 9 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER3.2-12S | 12 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER3.2-15S | 15 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| MLER3.218S | 18 | 5/0.8 | 3.2/0.45 | 5/20 | 0.37 | |
| 5000 | MLER05-06S | 6 | 5/0.8 | 6.1/1 | 5/20 | 0.37 |
| MLER05-09S | 9 | 5/0.8 | 6.1/1 | 5/20 | 0.37 | |
| MLER05-12S | 12 | 5/0.8 | 6.1/1 | 5/20 | 0.37 | |
| MLER05-15S | 15 | 5/0.8 | 6.1/1 | 5/20 | 0.37 | |
| MLER05-18S | 18 | 5/0.8 | 6.1/1 | 5/20 | 0.37 | |
| 10000 | MLER10-06S | 6 | 5/0.8 | 9.5/1.5 | 5/20 | 0.75 |
| MLER10-09S | 9 | 5/0.8 | 9.5/1.5 | 5/20 | 0.75 | |
| MLER10-12S | 12 | 5/0.8 | 9.5/1.5 | 5/20 | 0.75 | |
| MLER10-15S | 15 | 5/0.8 | 9.5/1.5 | 5/20 | 0.75 | |
| MLER10-18S | 18 | 5/0.8 | 9.5/1.5 | 5/20 | 0.75 | |
| MLER10-20S | 20 | 8/1.3 | 16/2.6 | 5/20 | 0.75 | |
| MLER10-24S | 24 | 8/1.3 | 16/2.6 | 5/20 | 0.75 | |
| MLER10-28S | 28 | 8/1.3 | 16/2.6 | 5/20 | 0.75 | |
| MLER10-32S | 32 | 8/1.3 | 16/2.6 | 5/20 | 0.75 | |
| MLER10-36S | 36 | 8/1.3 | 16/2.6 | 5/20 | 0.75 | |
| 20000 | MLER20-06S | 6 | 4/0.6 | 16/2.6 | 5/20 | 0.75*2 |
| MLER20-09S | 9 | 4/0.6 | 16/2.6 | 5/20 | 0.75*2 | |
| MLER20-12S | 12 | 4/0.6 | 16/2.6 | 5/20 | 0.75*2 | |
| MLER20-15S | 15 | 4/0.6 | 16/2.6 | 5/20 | 0.75*2 | |
| MLER20-18S | 18 | 4/0.6 | 16/2.6 | 5/20 | 0.75*2 |
